KAIWEETS HT206A is a True-RMS digital auto-ranging clamp meter. It is the perfect troubleshooting tool for commercial and residential electricians. Its slim and compact size makes it easy to operate in narrow spaces. You can use it to measure Current, Voltage, Continuity, Diode, Capacitance, Resistance and Continuity of circuits, switches, fuses, and contacts.
Specifications:
AC Current Range: 4A / 40A / 400A / 600A Accuracy: ±(2.5%+5)
DC Voltage Range: 400mV / 4V / 40V / 400V / 600V Accuracy: ±(0.5%+5)
AC Voltage Range: 4V / 40V / 400V / 600V Accuracy: ±(1.0%+5)
Resistance Range: 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ Accuracy: ±(1.0%+5)
Capacitance Range: 4nF / 40nF / 400nF / 4uF / 40uF / 400uF / 4mF Accuracy: ±(4.0%+5)
Security standard IEC 61010-1, IEC 61010-2-032 IEC 61010-030, IEC61010 CAT.III 600V
Pollution level 2
Operating temperature 0 to +40 ℃
Operating humidity <80% RH, <10°C non condensing
Operating height 0 to max. 2000 m
Storage temperature - 10 to +60 ℃
Air humidity in storage <70%
